氣源處理器使用的注意事項氣動電磁閥廠

氣源處理器使用的注意事項

Cautions in Application of F.R.L Equipment氣源處理器使用的注意事項

一、安裝注意事項:(cautions in installation)

 ●氣源處理器安裝時過濾器、過濾減壓閥、油霧器必須垂直安裝,水杯向下,減壓閥調壓旋鈕向下,且氣體流動方向必須按殼體上箭頭所示方向。

 ●安裝時請考慮一定的安裝與維護空間(如過濾器的安裝高度以能卸下水杯為準),氣源處理器避免安裝在有較強振動的環境中,以維護壓力表精度及連接件強度。

●盡量避免安裝在陽光直射的場合。

●Clean the pipes before installation of pneumatic components  associated,Remove dust、oil、debris、etc.to prevent the fragments of sealing material mix。

●When installed,  the filter、filter regulator and lubricator must be vertically, the cup down, the knob of regulator down, and the gas flow direction must be consistent with the arrow on valve body。

●Before installation, please set some space for installation and maintenance (such as the height of filters mounting ,to be able to remove the cup)。FRL should be avoid installed in a strong vibration environment ,to protect the accuracy of pressure gauge and the strength of the connection。

●Avoid to installation in sunshine point-blank  occasion。

二、使用時注意事項:(Cautions in usage)方向控制閥廠家

●過濾器應定期清洗濾芯,否則經過過濾器后系統壓力降將會增大。濾芯與杯子請用家庭用中性清洗劑清洗,然后用清水漂凈。

●請根據使用環境和氣壓系統要求選擇合理的過濾器大小及排水方式。

●水杯與油杯材質為聚碳酸酯,應避免與四氯化碳、酸類、堿類、苯胺、煤油和其它對聚碳酸脂起化學反應的化學物品。

●確認過濾器及過濾減壓閥杯子或杯子護罩正確到位后,方可開啟壓力,在加壓狀態下切勿旋轉杯子及其護罩 。

●過濾減壓閥(W型)、減壓閥(R型)使用時將調壓旋鈕拔出調至使用壓力,調完后將調壓旋鈕推入(止旋)。根據使用情況選擇相應的壓力表,方型壓力表和單向閥板組件可以進行互換。

●油霧器可在不停氣情況下加油。請將油杯內油量保持在油量上限與下限范圍內。L3000、L4000旋開注油塞,從注油塞口處加油。L1000、L2000將排氣塞旋開,排除殘余氣體,卸下杯子直接從杯口加油;然后將油杯旋入閥體,再將排氣塞擰緊。(油霧器使用ISO VG32或同級潤滑油)

●油霧器滴液流量的調節,用一字型調節工裝逆時針調節調油件滴液流量增加,順時針調節調油件滴液流量減少,調節過程中不能用力過大。

 ●殘壓排出:排出杯子內的壓力(F.W用放水旋塞、L1000、2000系列用排氣塞排氣、L3000、4000  系列用注油塞排氣)后,請確認壓力是否完全排除。

 ●氣源處理器中密封圈使用壽命3-5年,使用到期請進行更換。

●The filter should be cleaned regularly, otherwise the system pressure drop will increase. When cleaning the filter or the cup, use a neutral household detergent, then rinse with water.

●According to the work environment and the requirements of pneumatic system to select the appropriate filter such as size or drainage patterns。

●As the cup is made of polycarbonate, should avoid contact with carbon tetrachloride, acids, bases, aniline, kerosene and other chemicals be easy to reaction with polycarbonate.

●Before the open,make sure the cup or cup shield of the filter and filter regulator in right place。 Under the pressure, do not rotate the cup or shield.

●When using, please pull out the regulator knob such as filter regulator (W type) or regulator (R type), Adjusted to the desired pressure,Then push the regulator knob to prevent rotation. According to select the appropriate use of pressure gauge. Square gauge and check valve plate assembly can be interchanged.

●Please maintain the oil in the cup in the upper and lower limits. You can add oil in the case non-stop gas 。

1 for the L3000, L4000 series, first unscrew the fill plug, and add oil through the fill plug hole.

2 for L1000, L2000 series, first unscrew the vent plug, then remove the cup, add the oil directly to the cup; then screwed the cup into the valve, then tighten the vent plug. (Lubricator with oil ISO VG32 or Same level )

●Lubricator drip flow regulation: we can use a screwdriver to adjust the regulator. Counterclockwise, drip flow increases; clockwise, drip flow reduction. Note: The adjustment process can not be too hard.

●Discharge of residual pressure:The pressure within the exhaust cup (FW with drain cocks, L1000、2000 series with the exhaust vent plug, L3000、4000 series with the fill plug exhaust), make sure the pressure is completely ruled out.

●The normal life of the product seal is five years, to be replaced periodically.
